TDK (TDK-Lambda) TDK-Lambda Switching Power Supply 12V dc 50A 600W RWS600B-12

Output voltage = 12V dc
Output current = 50A
Rated power = 600W
Number of Outputs = 1
Input voltage = 120 → 370 V dc, 85 → 265 V ac
Mounting type = Chassis mount Package type = With cover Length = 61mm
Width = 120mm
Depth = 190mm
Efficiency = 81%, 84%
Weight = 1.6kg
TDK-Lambda Switch Mode Power SuppliesTDK-Lambda RWS-B series 600 W single output AC-DC embedded switch mode power supplies have an output current rating of 50 A at 12 V dc. The product has universal input power supply voltage ratings of 85 → 265 V ac and 120 → 330 V dc. This switch mode power supply is positioned as a mid-range product with simple features. It is housed in a simplified, compact, highly efficient power supply package. Improved efficiency at low loads and low power consumption in standby mode contribute to reducing the environmental impact. This power supply is internally cooled.Features and BenefitsHigh efficiency Level B EMI low profile Operating temperature range: -10 → 70°C Screw connectionApplicationsBroadcast Communication Industrial LED SignageTest & MeasurementCertificationsCE certified CSA certified EN60950-1 UL recognized
