OMRON Mini Power Relay MY3
#Grup produk P112441890
Spesifikasi
| CR Circuit | None |
|---|---|
| Contact Configuration | 3c |
| Contact Material | Ag |
| Contact Resistance (miliΩ) | 50 or less (DC5V 1A voltage drop method) |
| Electrical Durability | More than 500,000 times (rated load, switching frequency 1800 times/h, ambient temperature condition 23°C) |
| Insulation Resistance (MΩ) | 100 or more (measured with the DC500V insulation resistance meter at the same location as the withstand voltage) |
| Maximum Permissible Voltage (V) | 110% of rated voltage |
| Mechanical Durability | AC 50 million times or more (switching frequency 18,000 times/h), DC 100 million times or more (switching frequency 18,000 times/h) |
| Number of Pins | 11 |
| Number of Poles | 3 |
| Protection Class | Closed type (cased) |
| Type | Mini Power Relay |
Pilih jenis produk yang diinginkan
| Nomor SKU | Model Number | Masa Persiapan Barang | Harga | Jumlah |
|---|---|---|---|---|
| Loading... | ||||
Apakah produk dengan spesifikasi yang Anda inginkan belum tersedia? Hubungi tim Layanan Pelanggan kami di sini
Informasi Produk
Feature
Eliminates the use of lead and supports environmental protection.Obtained additional VDE standard (Germany) and IMQ standard (Italy).
By changing the color of the AC / DC coil tape, the distinguishability of AC / DC specifications is improved.
