Line Seiki Pulse Filter (DIN Case)
#Grup produk P112435066
Spesifikasi
| Display | 7-segment LCD, 4 digits, character height: 7mm |
|---|---|
| Function | Pulse Filter |
| Input | Pulse input (Input)/Key protect (K/P) |
| Input Signal | Non-contact/contact input: Open collector input L<2V (current flow approx. 1mA) |
| Memory | E2PROM Data retention for 10 years Rewrite count 10,000 times |
| Output | Non-contact output: NPN open collector input (DC30V 100mA max.) / Relay output: 1c contact (AC/DC30V 0.5A max.) |
| Output Type | One shot (100ms) |
| Power Supply | DC12-24V (-15%-+10%) |
| Setting Range | 0.1 -999.9 |
| Specification | ●Key protection: Activated by key protection input ●Input speed: 10Hz (pulse input [Input]) |
Pilih jenis produk yang diinginkan
| Nomor SKU | Model Number | Masa Persiapan Barang | Harga | Jumlah |
|---|---|---|---|---|
| Loading... | ||||
Apakah produk dengan spesifikasi yang Anda inginkan belum tersedia? Hubungi tim Layanan Pelanggan kami di sini
Informasi Produk
Feature
Pulse converter An option that controls the input pulse to the counter. Filters the pulses received within a set time and outputs them as one pulse. Combines multiple pulses from an area sensor into one pulse in equipment for injecting multiple parts at once, such as molding machines. Set time: 0.1 seconds to 999.9 seconds. Includes a key protect function to prevent incorrect operation (terminal input).DIN rail mounting
