Line Seiki Logic Filter (DIN Case)
#Grup produk P112434711
Spesifikasi
| Display | 7-segment LCD, 4 digits, character height: 7mm |
|---|---|
| Function | Logic Filters |
| Input | Pulse input (Input)/Logic 1 (Logic1)/Logic 2 (Logic2)/Logic 3 (Logic3)/Logic 4 (Logic4)/Key protect (K/P) |
| Input Signal | Non-contact/contact input: Open collector input L<2V (current flow approx. 1mA) |
| Memory | E2PROM Data retention for 10 years Rewrite count 10,000 times |
| Output | Non-contact output: NPN open collector input (DC30V 100mA max.) / Relay output: 1c contact (AC/DC30V 0.5A max.) |
| Output Type | Hold (logical match output) |
| Power Supply | DC12-24V (-15%-+10%) |
| Setting Range | LLLL-HHHH (16 ways) |
| Specification | ●Key protection: Activated by key protection input ●Input speed: 10Hz (pulse input [Input]) |
Pilih jenis produk yang diinginkan
| Nomor SKU | Model Number | Masa Persiapan Barang | Harga | Jumlah |
|---|---|---|---|---|
| Loading... | ||||
Apakah produk dengan spesifikasi yang Anda inginkan belum tersedia? Hubungi tim Layanan Pelanggan kami di sini
Informasi Produk
Feature
Logical filter that controls pulses Option to control input pulses to the counter Allows the passage of input pulses only when four input logics (H/L) match Input logic can be set by terminal input Pulses can be passed and counted only under specific operating conditions Key protection function to prevent operational errors (terminal input)DIN rail mounting
