Kusam Meco High Voltage Probe
#Grup produk P112422503
Spesifikasi
| Accuracy | DCV (0 - 20kV) ± 1%, DCV (20 kV - 40kV) ± 2%, ACV (0 - 28 kV) typically ± 5% at 50 Hz |
|---|---|
| Attenuation Ratio | 1000:1 |
| Cable Length (m) | 1 |
| Input Impedance (MW) | 1000 |
| Maximum Working Voltage (V) | 40k DC or 28k AC |
| Operating Temperature (°C) | 0 to 50 <80% RH |
| Storage Temperature (°C) | -10 to 60 (<80% R.H.) |
Pilih jenis produk yang diinginkan
| Nomor SKU | Model Number | Masa Persiapan Barang | Harga | Jumlah |
|---|---|---|---|---|
| Loading... | ||||
Apakah produk dengan spesifikasi yang Anda inginkan belum tersedia? Hubungi tim Layanan Pelanggan kami di sini
Informasi Produk
Feature
High Voltage ProbeModel PD-28
Most Digital Multimeters can measure AC Voltage up to 750 /1000V and DC Voltage upto 1000V DC. To extend the measuring range of the digital multi meter for low - power, high - voltage, high impedance circuits such as TV, Video Monitors.
• PD - 28 is a High Voltage Probe used to measure both AC & DC voltage with your Multimeter.
• It consist of 2 kinds of contact tips : One is a round needle tip for normal use. The other is a special flat spring type for CRT anode.
• A separate test clip for the ground connection is provided.
• A set of test leads for connecting to the Multimeter & a high quality enclosure which has very High Insulation properties.y
• It has a ergonomically designed handle for convenient use.
• It can be used with most Digital Multimeters.
