SIEMENS Multiple Input Receiver-Controller
#Grup produk P112386849
Spesifikasi
| Adjustment Method | Rotary Knob; Screwdriver |
|---|---|
| Air Consumption (scim) | 60 |
| Application | Hospitals; Humidity; Offices; Pressures of Mechanical Equipment in Commercial Building; Schools; Temperatures; Universities |
| Authority - Maximum (%) | 200 |
| Authority - Minimum (%) | 20 |
| Control Action | Direct Acting |
| Control Signal | Proportional |
| Inlet Port Connection Size | 6 mm; 1/4 in |
| Inlet Port Connection Type | Barbed Hose |
| Mounting | Surface |
| Number of Inlet Ports | 1 |
| Operating Humidity - Maximum (%) | 80 |
| Operating Humidity - Minimum (%) | 20 |
| Operating Temperature - Maximum (°F) | 120 |
| Operating Temperature - Minimum (°F) | 40 |
| Outlet Port Connection Size | 6 mm; 1/4 in |
| Outlet Port Connection Type | Barbed Hose |
| Overall Depth (inch) | 3-1/2 |
| Overall Length (inch) | 6-3/4 |
| Overall Width (inch) | 5-11/16 |
| Signal Pressure - Maximum (psi) | 15 |
| Signal Pressure - Minimum (psi) | 3 |
| Standards | REACH; RoHS Compliant |
| Supply Pressure (psi) | 22 |
| Throttling Range - Maximum (%) | 16 |
| Throttling Range - Minimum (%) | 2 |
| UNSPSC | 31160000 |
Pilih jenis produk yang diinginkan
| Nomor SKU | Model Number | Masa Persiapan Barang | Harga | Jumlah |
|---|---|---|---|---|
| Loading... | ||||
Apakah produk dengan spesifikasi yang Anda inginkan belum tersedia? Hubungi tim Layanan Pelanggan kami di sini
Informasi Produk
Description
These controllers connect to a single pneumatic sensor, monitor it for changes, and send proportional control signals to HVAC components to maintain specific conditions.
