SIEMENS Fan Coil Unit Thermostat
#Grup produk P112373146
Spesifikasi
| Application | Heat or Cool |
|---|---|
| Backlit Screen | Yes |
| Changeover Type | Automatic and Manual |
| Compatible System Type | Fan Coil Unit |
| Contact Type | Window |
| Control Type | Button |
| Display Type | Digital |
| Electrical Connection Type | Screw Terminals |
| Fan Settings | High; Low; Medium |
| Frequency (Hz) | 50; 60 |
| Housing Color | White |
| Housing Material | Plastic |
| Key Pad Lockout | Yes |
| Lead Wire Gauge (mm) | 2 |
| Maximum Operating Humidity (%) | 90 |
| Maximum Operating Temperature (°F) | 122 |
| Minimum Operating Temperature (°F) | 32 |
| Mounting Direction | Vertical |
| Mounting Location | Wall |
| Mounting Type | Conduit Box |
| Number of Relay Outputs | 3 |
| Occupancy Sensor | Includes Onboard Occupancy Sensor |
| Overall Depth (inch) | 1-1/8 |
| Overall Height (inch) | 3-3/4 |
| Overall Width (inch) | 3-3/4 |
| Programming Capability | Fully Programmable |
| Sensor Location | Built-In |
| Sensor Type | NTC Linearized 15 kohm Thermistor |
| Shape | Rectangle |
| Standards | EU; RoHS Compliant; UKCA; UL Listed |
| System Settings | Heat or Cool |
| Temperature Scale | Fahrenheit/Celsius |
| UNSPSC | 31160000 |
| Voltage (V) | 24 AC |
Pilih jenis produk yang diinginkan
| Nomor SKU | Model Number | Masa Persiapan Barang | Harga | Jumlah |
|---|---|---|---|---|
| Loading... | ||||
Apakah produk dengan spesifikasi yang Anda inginkan belum tersedia? Hubungi tim Layanan Pelanggan kami di sini
Informasi Produk
Description
These thermostats have a digital display and control temperatures of two- and four-pipe fan coil unit (FCU) systems. FCUs use a coil and fan to heat or cool a room. Indoor air moves over the coil to be heated or cooled before being released into the room. These thermostats allow for multiple settings of the fan's output to gradually heat or cool the room to the desired temperature. They're often installed in hotels, multifamily housing, schools, and other residential and commercial locations. These thermostats are nonprogrammable, so the temperature setting stays the same until it's readjusted.
