Coating Thickness Gauge with convenient one-hand operation / MIN MAX and MEAN display / Battery indicator / various units / automatic shutdown / for ferrous and non-ferrous metals / small and compact design
The coating thickness gauge is used for the quick and precise detection of layer thicknesses on metals. In comparison to many other coating thickness gauges, this coating thickness gauge does not have to differentiate between ferrous and non-ferrous metal. With the small and compact design of the coating thickness gauge, one-hand operation is possible. Despite its small size, the coating thickness gauge has a measuring range of 1500 µm and an accuracy of ± (3% + 1 µm).
The measured values displayed can be output in µm, mm and in mils on the coating thickness gauge. In addition to measuring the layer thickness, the coating thickness gauge can determine the smallest, the largest and also the mean value from a series of different measurements. The coating thickness gauge also has an automatic switch-off function.
Delivery Scope:
1 x Coating Thickness Gauge PCE-CT 25FN
5 x calibration foil reference
1 x Fe zero standard
1 x NFe zero standard
1 x 9 V block battery
1 x instruction manual
PCE Instruments Gun Type Coating Thickness Gauge
#Grup produk P112247708
Spesifikasi
| Dimensions (mm) | 143x85x39 |
|---|---|
| Housing Material | SECTION |
| Measurement Accuracy | ± (3% + 1 µm) |
| Measurement Units | µm, mm, mils |
| Measuring Range (µm) | 0-1500 |
| Operating Conditions (°C) | -10 to 50 (20 to 90% RH non-condensing) |
| Power Supply | 9V Block Battery |
| Resolution (µm) | 0.1in the measuring range 0-100; 1in the measuring range> 100 |
| Storage Conditions (°C) | -10 to 60 (20 to 90% RH non-condensing) |
