RS PRO 250V Miniature Vertical Float Switch (24 x 43mm)
A hardwearing food safe miniature float switch ideal for use with water dispensers, tank monitoring systems, vending machines, coffee machines and printing machines. Constructed from hardwearing Polypropylene housing sealed to IP67 for protection from contamination.
Designed for versatility the 250V float switch can be fitted to the top or bottom mounted within the tank and when mounted with the stem up the operating function is reversed.
Easy to install the vertical food safe float switch is fitted with a 24 AWG 300mm UL 1007 lead and is suitable for operating temperatures of -20°C to +80°C.
Versions Available:
(519-232) - N/O 250Vac 24mm dia 43mm long
RS PRO Vertical Polypropylene Float Switch
#Grup produk P112235475
Spesifikasi
| Body Material | PP |
|---|---|
| Cable Length (mm) | 300 |
| Device Type | Float |
| For use with | Water, Dilute Acid, Detergent |
| Gasket Material | Silicone |
| Interface | Cable |
| Maximum DC Voltage (V) | 200 |
| Maximum Operating Temperature (°C) | 80 |
| Maximum Pressure (bar) | 1 |
| Minimum Operating Temperature (°C) | -20 |
| Mounting Type | Vertical |
| Standards Met | FDA |
| Switch Output | Direct Load |
Pilih jenis produk yang diinginkan
| Nomor SKU | Model Number | Masa Persiapan Barang | Harga | Jumlah |
|---|---|---|---|---|
| Loading... | ||||
Apakah produk dengan spesifikasi yang Anda inginkan belum tersedia? Hubungi tim Layanan Pelanggan kami di sini
Informasi Produk
Description
Feature
Features and BenefitsVertical float switch
Normally open (N/O)
Food safe
Polypropylene construction
Contact rating of 50W/VA
Switching current of 1.5A
Float diameter of 24mm
Total length of 43mm
