RS Pro PID Temperature Controller 1/8 DIN
The 1/8 DIN PID temperature controllers are designed to provide temperature control in an easy to install, fast to program device. The temperature is displayed on a large, highly improved LED display and can be used in various applications, such as sealers.
RS PRO Panel Mount PID Temperature Controller
#Grup produk P112207560
Sebelum PPN:
Rp7.499.900 - Rp9.999.900
Ketersediaan:
Periksa Metode Pembayaran dan Estimasi pengiriman
Spesifikasi
| Additional Function | PID Function Only |
|---|---|
| Display Type | Dual 4 Digit LED |
| IP Rating | IP20, IP65 |
| Input Type | Analogue, B Type Thermocouple, C Type Thermocouple, J Type Thermocouple, K Type Thermocouple, L Type Thermocouple, N Type Thermocouple, PT100, R Type Thermocouple, S Type Thermocouple, T Type Thermocouple |
| Maximum Operating Temperature (°C) | 55 |
| Minimum Operating Temperature (°C) | 0 |
| Mounting Type | Panel Mount |
| Panel Depth (mm) | 67 |
Pilih jenis produk yang diinginkan
| Nomor SKU | Model Number | Masa Persiapan Barang | Harga | Jumlah |
|---|---|---|---|---|
| Loading... | ||||
Apakah produk dengan spesifikasi yang Anda inginkan belum tersedia? Hubungi tim Layanan Pelanggan kami di sini
Informasi Produk
Description
Feature
Features and Benefits• 1/8 DIN (96 x 48 mm)
• Large clear LED display
• 3 Button operation
• Universal input
• Up to 3 outputs with a choice of either relay or SSR
• 2 Process alarms, high/low, deviation or band
• Thermocouple, PT100 or linear DC sensor input
• Selectable indictor mode
• Quick setup menu with top 10 configuration parameters
• Easy installation
• Front panel configuration
• Suitable for applications where primary temperature control functions, such as heat only or heat/cool are needed
Temperature Range
+100 - +1824 (Type B Thermocouple), 0 - +1399 (Type N Thermocouple), 0 - +1762 (Type S Thermocouple), 0 - +1795 (Type R Thermocouple), 0 - +2320 (Type C Thermocouple), 0 - +762 (Type L Thermocouple), -199 - +800 (PT100), -200 - +1200 (Type J Thermocouple), -240 - +1373 (Type K Thermocouple)
