EZO Ball Bearing SR Type
#Grup produk P112179072
Spesifikasi
| Abutment and Fillet Dimension Da Max. (mm) | 11.5 |
|---|---|
| Abutment and Fillet Dimension Da Min. (mm) | 11.1 |
| Abutment and Fillet Dimensions da Max. (mm) | 7.9 |
| Abutment and Fillet Dimensions da Min. (mm) | 7.6 |
| Abutment and Fillet Dimensions rase Max. (mm) | 0.15 |
| Abutment and Fillet Dimensions rasi Max. (mm) | 0.15 |
| Ball Size (mm) x Quantity | 2.000x8 |
| Basic Dynamic Load Rating Cr (N) | 920 |
| Basic static load rating Cor (N) | 350 |
| Bore Diameter d (mm) | 6.35 |
| Inner Ring Chamfer Dimension (rsi min) (mm) | 0.15 |
| Inner Ring Width B (mm) | 3.175 |
| Limiting Speeds-Grease (min1) | 48000 |
| Limiting Speeds-Oil (min1) | 56000 |
| Outer Diameter d (mm) | 12.7 |
| Outer Ring Chamfer Dimension (rse min) (mm) | 0.15 |
| Outer Ring Width C (mm) | 3.175 |
Pilih jenis produk yang diinginkan
| Nomor SKU | Model Number | Masa Persiapan Barang | Harga | Jumlah |
|---|---|---|---|---|
| Loading... | ||||
Apakah produk dengan spesifikasi yang Anda inginkan belum tersedia? Hubungi tim Layanan Pelanggan kami di sini
