Yoshitake Solenoid Valve / REDMAN DD-3
#Grup produk P111936090
Sebelum PPN:
Rp3.499.900 - Rp3.899.900
Ketersediaan:
Periksa Metode Pembayaran dan Estimasi pengiriman
Spesifikasi
| Connector | JIS Rc |
|---|---|
| Cv value | 1.7 |
| Kinds | Solenoid Valve |
| Material | Plunger: SCS14A |
| Material (Main Unit) | SCS14A |
| Material (disc) | FKM (Viton) |
| Maximum Operating Pressure (MPa) | 0 to 0.15 |
| Maximum Temperature (°C) | 100 |
| Operating Pressure Range (MPa) | 0 to 0.15 |
| Operating Temperature Range (°C) | 100 |
| Orifice (mm) | 9.5 |
| Suitable fluid | Cold / hot water / air / oil (20 cSt or less) |
| Type | DD type (direct acting type) |
| Type of Acting | Open type when energized |
| format | Direct Acting |
Pilih jenis produk yang diinginkan
| Nomor SKU | Model Number | Masa Persiapan Barang | Harga | Jumlah |
|---|---|---|---|---|
| Loading... | ||||
Apakah produk dengan spesifikasi yang Anda inginkan belum tersedia? Hubungi tim Layanan Pelanggan kami di sini
Informasi Produk
Description
Stainless steel (SCS14A) direct acting solenoid valve. The mounting posture can be horizontal or vertical (however, pipe the coil so that it is above the horizontal). The coil protection structure is IP64 (dust-resistant, pine-proof), 100V / 200V selection type.
