Yoshitake Solenoid Valve / REDMAN (With Terminal Box) DP-100 (AC100V Specification)
#Grup produk P111936036
Sebelum PPN:
Rp8.099.900 - Rp9.899.900
Ketersediaan:
Periksa Metode Pembayaran dan Estimasi pengiriman
Spesifikasi
| Ambient Temperature (°C) | 50 or less (no freezing) |
|---|---|
| Connector | JIS Rc |
| Kinds | Solenoid Valve |
| Material (Gasket) | PTFE (fluorine resin) |
| Material (Valve Box) | SCS14A |
| Material (Valve Member) | SCS14A |
| Material (disc) | PTFE (fluorine resin) |
| Maximum Temperature (°C) | 180 (non-freezing) |
| Protection Class | IP64 |
| Protective Structure | Dust resistance and eyelash protection |
| Suitable fluid | Steam, air, cold / hot water, oil (20 cSt or less), nitrogen gas / argon gas / carbon dioxide (dry state) |
| Type | DP type (Pilot type) |
| Voltage (V) | AC100 / 50 / 60Hz shared |
| format | Piston type |
Pilih jenis produk yang diinginkan
| Nomor SKU | Model Number | Masa Persiapan Barang | Harga | Jumlah |
|---|---|---|---|---|
| Loading... | ||||
Apakah produk dengan spesifikasi yang Anda inginkan belum tersedia? Hubungi tim Layanan Pelanggan kami di sini
Informasi Produk
Description
Body made of stainless steel (SCS14A). Durability and scale resistance 3 times higher than conventional products. Free horizontal/vertical mounting (within 90° to the upward direction of the coil). Gasket adopts PTFE that emphasizes airtightness. There are two types of coils, one for 10A to 25A (red) and one for 32A to 50A (black).
