Yoshitake Pressure Reducing Valve with Bypass GD-27BP CAC Bronze Flange End Connection
#Grup produk P111934551
Sebelum PPN:
Rp24.999.900 - Rp109.999.900
Ketersediaan:
Periksa Metode Pembayaran dan Estimasi pengiriman
Spesifikasi
| Connector | JIS 10KFF flange |
|---|---|
| Diaphragm Material | Chlorine resistant EPDM |
| Material (Main Unit) | CAC (Leadless processing) |
| Material (O-ring) | Chlorine resistant EPDM |
| Material (Valve Member) | FKM (Viton) |
| Material (Valve Seat) | CAC (Leadless processing) |
| Maximum Decompression Ratio | 10：1 |
| Maximum Temperature (°C) | 90 |
| Operating Temperature Range (°C) | 90 |
| Primary Pressure (MPa) | 1.0 or less |
| Primary Side Suitable Pressure (MPa) | 1.0 or less |
| Suitable fluid | Cold And Hot Water |
| Type | Direct Acting |
Pilih jenis produk yang diinginkan
| Nomor SKU | Model Number | Masa Persiapan Barang | Harga | Jumlah |
|---|---|---|---|---|
| Loading... | ||||
Apakah produk dengan spesifikasi yang Anda inginkan belum tersedia? Hubungi tim Layanan Pelanggan kami di sini
Informasi Produk
Description
A pressure reducing valve for water that has a bypass and closing function in addition to the pressure reducing function. Bypass function enables cleaning and water flow in the pipe at the initial stage of water flow. Corrosion resistant material (chlorine resistant EPDM for diaphragm and O-ring) is used for the wetted parts, and it has excellent chlorine resistance to tap water. With a sealed structure, even if the diaphragm is damaged, it will not leak to the outside. Water supply law standard compliant product (E-179)
