Yoshitake Pressure Reducing Valve GP-1001 FCD450 Flange End Connection
#Grup produk P111934357
Sebelum PPN:
Rp9.699.900 - Rp43.999.900
Ketersediaan:
Periksa Metode Pembayaran dan Estimasi pengiriman
Spesifikasi
| Connector | JIS 10KFF flange |
|---|---|
| Diaphragm Material | SUS |
| Material (Main Unit) | FCD450 |
| Material (Piston / Cylinder) | C 3640 or CAC |
| Material (Valve / Valve Seat) | SUS |
| Maximum Decompression Ratio | 20：1 |
| Maximum Temperature (°C) | 220 |
| Operating Temperature Range (°C) | 220 |
| Primary Pressure (MPa) | 0.1 to 1.0 |
| Primary Side Suitable Pressure (MPa) | 0.1 to 1.0 |
| Secondary Adjustment Pressure (MPa) | 90% or less of primary pressure (gauge pressure) |
| Secondary Pressure (MPa) | 0.05 to 0.9 |
| Secondary Pressure Adjustment Range (MPa) | 0.05 to 0.9 |
| Suitable fluid | Steam |
| Type | Pilot Type Piston Type |
Pilih jenis produk yang diinginkan
| Nomor SKU | Model Number | Masa Persiapan Barang | Harga | Jumlah |
|---|---|---|---|---|
| Loading... | ||||
Apakah produk dengan spesifikasi yang Anda inginkan belum tersedia? Hubungi tim Layanan Pelanggan kami di sini
Informasi Produk
Description
Excellent sealing performance and small amount of valve seat leakage. Pressure adjustment can be easily done by operating the handle.
