Yoshitake Pressure Reducing Valve GP-1000T FCD450 Flange End Connection
#Grup produk P111934311
Sebelum PPN:
Rp11.999.900 - Rp54.999.900
Ketersediaan:
Periksa Metode Pembayaran dan Estimasi pengiriman
Spesifikasi
| Connector | JIS 10KFF flange |
|---|---|
| Diaphragm Material | SUS |
| Material (Main Unit) | FCD450 |
| Material (Piston / Cylinder) | C 3640 or CAC |
| Material (Valve / Valve Seat) | Synthetic Rubber / C3604 / SUS |
| Maximum Decompression Ratio | 20：1 |
| Maximum Temperature (°C) | 80 |
| Operating Temperature Range (°C) | 80 |
| Primary Pressure (MPa) | 0.1 to 1.0 |
| Primary Side Suitable Pressure (MPa) | 0.1 to 1.0 |
| Secondary Adjustment Pressure (MPa) | 90% or less of primary pressure (gauge pressure) |
| Secondary Pressure (MPa) | 0.05 to 0.9 |
| Secondary Pressure Adjustment Range (MPa) | 0.05 to 0.9 |
| Suitable fluid | Air, other non-hazardous fluid |
| Type | Pilot Type Piston Type |
Pilih jenis produk yang diinginkan
| Nomor SKU | Model Number | Masa Persiapan Barang | Harga | Jumlah |
|---|---|---|---|---|
| Loading... | ||||
Apakah produk dengan spesifikasi yang Anda inginkan belum tersedia? Hubungi tim Layanan Pelanggan kami di sini
Informasi Produk
Description
Non-leak type with zero valve seat leakage. Compliant with SHASE-S106 pressure reducing valve (Air Conditioning and Sanitary Engineering Society) standards.
