Yoshitake Pressure Reducing Valve GD-200 FCD450 Flange End Connection
#Grup produk P111933419
Sebelum PPN:
Rp27.999.900 - Rp129.999.900
Ketersediaan:
Periksa Metode Pembayaran dan Estimasi pengiriman
Spesifikasi
| Connector | JIS 10KFF flange |
|---|---|
| Diaphragm Material | NBR |
| Material (Main Unit) | FCD450 |
| Material (Valve Member) | NBR |
| Material (Valve Seat) | SUS |
| Maximum Decompression Ratio | 10：1 |
| Maximum Temperature (°C) | 80 |
| Minimum Differential Pressure (MPa) | 0.05 |
| Operating Temperature Range (°C) | 80 |
| Primary Pressure (MPa) | 1 or less |
| Primary Side Suitable Pressure (MPa) | 1 or less |
| Suitable fluid | Cold / hot water, oil (kerosene, A / B heavy oil), air |
| Type | Direct Acting |
Pilih jenis produk yang diinginkan
| Nomor SKU | Model Number | Masa Persiapan Barang | Harga | Jumlah |
|---|---|---|---|---|
| Loading... | ||||
Apakah produk dengan spesifikasi yang Anda inginkan belum tersedia? Hubungi tim Layanan Pelanggan kami di sini
Informasi Produk
Description
Maintains stable secondary side pressure. Stainless steel is used for the valve seat for excellent durability. Disassembly from one direction on the top side allows internal inspection and easy maintenance and inspection.
