Yoshitake Expansion Joint EB-1J
#Grup produk P111932270
Sebelum PPN:
Rp16.999.900 - Rp36.999.900
Ketersediaan:
Periksa Metode Pembayaran dan Estimasi pengiriman
Spesifikasi
| Connector | JIS 10K flange |
|---|---|
| Expansion / Contraction (mm) | Stretch 10 Shrink 25 |
| Material | Outer cylinder: SPHC or SS, bellows, inner cylinder: SUS316L |
| Material (Bellows) | SUS316L |
| Material (Outer Pipe) | Carbon steel |
| Maximum Operating Pressure (MPa) | 1 |
| Maximum Pressure (MPa) | 1 |
| Maximum Temperature (°C) | 220 |
| Operating Temperature Range (°C) | 220 |
| Range of Length Adjustment | Maximum extension / contraction length: Elongation 10, contraction 25 |
| Suitable fluid | Steam, air, cold / hot water, oil, other non-hazardous fluids |
| Type | Telescopic fittings |
| format | Bellows type (Single type A) |
Pilih jenis produk yang diinginkan
| Nomor SKU | Model Number | Masa Persiapan Barang | Harga | Jumlah |
|---|---|---|---|---|
| Loading... | ||||
Apakah produk dengan spesifikasi yang Anda inginkan belum tersedia? Hubungi tim Layanan Pelanggan kami di sini
Informasi Produk
Description
Absorbs expansion and contraction in the axial direction of the pipeline due to temperature changes. Compliant with Japanese Industrial Standard JIS B 2352. Excellent corrosion resistance and durability as the liquid-contacting parts are made of stainless steel.
