Yoshitake Diaphragm Solenoid Valve (Thread Type) DP-200 Series
#Grup produk P111931952
Sebelum PPN:
Rp4.699.900 - Rp12.999.900
Ketersediaan:
Periksa Metode Pembayaran dan Estimasi pengiriman
Spesifikasi
| Applicable Pressure Range (MPa) | 0 to 1 (cannot use vacuum) |
|---|---|
| Connector | JIS Rc |
| Fluid | Cold / hot water, air, nitrogen gas, carbon dioxide gas (dry state), argon gas, oil (20 cSt or less: kerosene, light oil grade) |
| Handle Type | Without handle |
| Kinds | Solenoid Valve |
| Material (Main Unit) | CAC |
| Material (Valve Member) | NBR (diaphragm) |
| Maximum Operating Pressure (MPa) | 1 |
| Minimum Operating Pressure Differential (MPa) | 0 (Differential pressure of 0.1 or more is required for horizontal coils) |
| Mounting Direction | Horizontal/vertical piping (within 90° to the upward direction of the coil) |
| Operating Temperature Range (°C) | 5 to 60 (no freezing) |
| Operation | Open when energized |
| Shape | Straight |
| Suitable fluid | Cold / hot water, air, nitrogen gas, argon gas, oil (20 cSt or less) |
| Type of Connection | Screw-in type |
| format | Pilot type diaphragm |
Pilih jenis produk yang diinginkan
| Nomor SKU | Model Number | Masa Persiapan Barang | Harga | Jumlah |
|---|---|---|---|---|
| Loading... | ||||
Apakah produk dengan spesifikasi yang Anda inginkan belum tersedia? Hubungi tim Layanan Pelanggan kami di sini
Informasi Produk
Description
Reduces the impact of water hammer & shortens valve closing time No valve seat leakage (visually check with pressure gauge) Can be used for a wide range of pressures from 0 to 1.0 MPa.
