Yoshitake Air Operated Pressure Reducing Valve + Operation Standard
#Grup produk P111931110
Spesifikasi
| Connector | JIS Rc1/4 |
|---|---|
| Filtration (µm) | 5 |
| Fluid Temperature (°C) | 5 to 60 |
| Nominal Diameter (B) | 1/4 |
| Nominal Diameter A | 8 |
| Primary Pressure (MPa) | 0.99 or less |
| Primary Side Suitable Pressure (MPa) | 0.99 or less |
| Secondary Pressure (MPa) | 0.05 to 0.7 |
| Secondary Pressure Adjustment Range (MPa) | 0.05 to 0.7 |
| Suitable fluid | Air |
| Withstand Pressure (MPa) | (Body) 1.5 |
Pilih jenis produk yang diinginkan
| Nomor SKU | Model Number | Masa Persiapan Barang | Harga | Jumlah |
|---|---|---|---|---|
| Loading... | ||||
Apakah produk dengan spesifikasi yang Anda inginkan belum tersedia? Hubungi tim Layanan Pelanggan kami di sini
Informasi Produk
Description
The standard unit for operating the air-operated pressure reducing valve is the air pressure reducing valve with filter (GD-37N), It is a combination of necessary equipment such as a pressure gauge, a manual three-way switching valve, an exhaust throttle valve, and a mounting bracket, and is manufactured so that the performance of the air-operated pressure reducing valve can be fully utilized. Also, use it for operating air-operated valves (PD-1, PD-2, PD-3).
