The ultra-thin beam sensor is just 3.5mm thick and can be installed anywhere there is a small space.
Its high-speed response of 0.5ms makes it ideal for detecting small parts and fast-moving objects.
Panasonic (Panasonic Industrial Devices SUNX) Ultra-thin Beam Sensor
#Grup produk P111922556
Spesifikasi
| Detection Method | Transparent type |
|---|---|
| Detection Distance (mm) | 500 |
| Type | Operation changeover switch relay type |
| Protective Structure | IP67 (IEC), waterproof type (JIS) |
| Repeatability (mm) | 0.05 or less (perpendicular to detection axis) |
| Output Method | NPN transistor open collector |
| Ambient Temperature (°C) | -25 to 55 (no condensation or freezing) |
| Case Material | Polyarylate |
| Current Consumption (mA) | Emitter: 10 or less, Receiver: 10 or less |
| Head Shape | corner |
| Insulation Resistance (MΩ) | DC250V 20 or more between live parts and case |
| Lens Material | Polyarylate |
| Operating Humidity Range (%RH) | 35～85 |
| Operation Indicator light | Orange LED (lights up when output is ON) |
| Power Supply Voltage (V) | 12 to 24 DC ±10%, Ripple P-P 10% or less |
| Storage Humidity Range (%RH) | 35～85 |
| Storage Temperature Range (°C) | -30～70 |
| Vibration Resistance Durability | 10 to 500Hz, double amplitude 3mm (MAX.20G), 2 hours each in XYZ directions |
| Withstand Voltage (V) | AC1000 for 1 minute between live parts and case |
