The new Gen-Eye Hot-Spot pipe locator makes locating easy. Its total field antenna array and on-screen icons lead you right to your target, without the long learning curve
Whether you’re an experienced pro or a first time user, you can quickly locate inspection cameras, sondes, active power lines and utility lines with pinpoint accuracy.
No need to interpret numbers and bar graphs.
The easy-to-see auto backlit LCD display shows you the way with arrows that point you in the right direction every time. Utility line location and active buried power line locating is just as easy.
The Hot-Spot is the industry’s most rugged pipe locator. Rated at IP65, it is dust and dirt proof, and water resistant. It passed the one meter drop test and the screen passed the 18” steel ball drop test.
General Tools & Instruments Hot-Spot Digital Pipe Locator
#Grup produk P111586752
Spesifikasi
| Active Power Line Frequencies (Hz) | 60/50 and 180/150 |
|---|---|
| Antenna Configuration | Total Field, Single Peak, Twin Peak, Null and Left/Right (Line Location Only) |
| Batteries | 2 D-cell alkaline (Approximately 30 hours of life) |
| Camera/Sonde Frequencies | 512 Hz and 33KHz |
| Depth Range (ft) | 10 in cast iron pipe / 20 in clay or plastic |
| External Ports | Mini USB |
| Line/Utility Frequencies (kHz) | 1, 8, 33, 65 |
| Operating Temperature Range (°C) | -20 to 50 |
| Operating Temperature Range (°F) | -4 to 122 |
| Screen | LCD Digital Signal Read-Out, Graphic Display, Directional Arrows, Null Icon, Camera Icon, Utility Icon, Audible Tone, Auto Digital Depth, Battery Status, Auto Backlight |
Pilih jenis produk yang diinginkan
| Nomor SKU | Model Number | Masa Persiapan Barang | Harga | Jumlah |
|---|---|---|---|---|
| Loading... | ||||
Apakah produk dengan spesifikasi yang Anda inginkan belum tersedia? Hubungi tim Layanan Pelanggan kami di sini
Informasi Produk
Description
Feature
HOT-SPOT PIPE LOCATOR FEATURESSuperior Battery Life
Lasts approximately 30 hours – more than twice as long as others. Automatic shutdown feature saves power.
Expanded Frequencies
Locates two sonde frequencies, two power frequencies and four line frequencies (with external transmitter).
Upgradeable Software
Use the USB port to upgrade software in the field or for a screen capture.
Simple, menu-based user interface
No need for multiple screens. Easy-to-access menus make it easier to use than other pipe locators.
Easy to read display
Icons lead you to your target. Auto backlight lets you locate in dimly lit areas.
Total field antenna array
Allows you to locate from any direction.
Line direction compass
Tells you the lay of the pipe.
Industry’s most rugged pipe locator:
Its IP65 rating is the industry’s highest for performing in dusty, dirty or wet jobsite conditions. Passed 1-meter drop test; screen passed 18″ steel ball drop test.
Made in U.S.A.
