Surface Mount Thermostat with Rigid Capillary
The surface mount thermostat works on the principle of volume expansion, if the temperature of the filling medium inside the probe increases the volume increases which results in the elevation of a diagrapm that triggers a microswitch.
IP54 Rated
1xSPDT switching contact
Temperature control or temperature monitoring functions
Differential of 3-4%
JUMO Capillary Thermostat
#Grup produk P111542192
Spesifikasi
| Contact Rating (A) | 10 |
|---|---|
| Maximum Temperature (°C) | 100 |
| Minimum Temperature (°C) | 0 (zero) |
| Mounting Type | Surface Mount |
| Reset Type | Automatic |
| Switch configuration | NO/NC |
| Terminal Type | Solder Tab |
| Thermostat Type | Capillary |
| contact Voltage Rating (V) | 230 ac/dc |
Pilih jenis produk yang diinginkan
| Nomor SKU | Model Number | Masa Persiapan Barang | Harga | Jumlah |
|---|---|---|---|---|
| Loading... | ||||
Apakah produk dengan spesifikasi yang Anda inginkan belum tersedia? Hubungi tim Layanan Pelanggan kami di sini
Informasi Produk
Description
Warning
Note : With the ATHs-1 the switching point can be adjusted from the outside, with the ATHs-2 the switching point can be adjusted on the inside. U= Screw in pocket, UZ=screw in pocket with extensionUlasan Produk
