-Single phase voltage, current, frequency and power factor True RMS measuring
-Clearly vision with 4 digits of red LED Display
-Auto Changing the display, Provide LED to indicated display values
-Programmable the ratio of CT& PT
-Interface with computer by RS-485, Modbus Protocol.
Primus Digital Volt-Hertz Meter True RMS with RS-485
#Grup produk P111518140
Spesifikasi
| Accuracy | 1 % ±1 digit |
|---|---|
| Ambient | 35 to 85 % RH |
| CT Ratio | 1 To 2000 |
| Communication | RS-485 |
| Current Range | 50mA. to 5.5 Amp (Direct), 10000A (with CT) |
| Dimensions (mm) | 96x96x96.5 |
| Display | 7 Segment, 4 Digit, 1 Row |
| Display Size (inch) | 0.56 |
| Frequency (Hz) | 50 |
| Frequency Range (Hz) | 45-55 |
| Operating Voltage (V) | 230 AC ±10% |
| PT Ratio | 1 To 1000 |
| Power Consumption (VA) | 4 |
| Protection | IP 40 |
| Protocol | MODBUS RTU |
| Range Current (A) | 0 - 9999. (5 direct input on instrument terminal, more than 5 must connect with standard CT secondary 5) |
| Range Voltage (V) | 0-500 AC (Line to Line & Line to Nutron) |
| Standard Size With (mm) | 96x96x80 |
| Voltage Range (V) | 10-500 (VL-N) |
| Working Temperature (°C) | -20 to 60 |
