Easy to see with 5 digit of red LED 7 segment display
'-Lock of value setting is supportable.
-Select input type by keypad.
-Provide 3 of alarms relay output (Maximum)
-Interface with computer by RS-485, Modbus Protocol.
-On/ Off time deley function
Primus Digital Ammeter
#Grup produk P111518025
Spesifikasi
| Accuracy | 0.3 % ±1 digit OFS |
|---|---|
| Alarm | Absolute High with On delay, Absolute Low with Off delay |
| Alarm Contact | SPDT |
| Alarm Contact Current (A) | 5 |
| Alarm Contact Voltage (V) | 250 |
| Alarm Sensitivity | 0 -10 % of range |
| Decimal Point | 0 or 0.00 Selectable |
| Indication | 4 digit 7 segment red LED |
| Input | Current transformer (C.T.) Range 0-5A AC DC shunt 0-60mV DC |
| Lock function | Parameter Lock, All Lock, Off Lock (Selectable) |
| Memory | Epprom |
| Multiplier | 1-2000 |
| Off Delay Time (s) | 0-60 Before Relay Stop For Low Alarm |
| On Delay Time (s) | 0-60 Before Relay Start For High Alarm |
| Sampling Time (µs) | 0.5 |
| Sensor Adjust | 0-10 % of Range |
| Supply Voltage (V) | 90-250 AC |
| Temperature Operating (°C) | 0-55 |
Pilih jenis produk yang diinginkan
| Nomor SKU | Model Number | Masa Persiapan Barang | Harga | Jumlah |
|---|---|---|---|---|
| Loading... | ||||
Apakah produk dengan spesifikasi yang Anda inginkan belum tersedia? Hubungi tim Layanan Pelanggan kami di sini
