Package Styles: SIP, cUL, IEC, CE, CCC and RoHS compliant. Plug-in, DIN/PCB Mount - ED Series. Crydom's DC Switching ED Series offers a DC output solid state relay series in an industry standard EMR plug-in package. This allows the device to be mounted either on a PCB (RS part numbers < 740-1365') 740-1365 or on a standard DIN rail (RS part numbers < 740-1368') 740-1368. DC output solid state relay in an industry standard EMR plug-in package. Rating: 5A Load Voltage Range: 1-48 and 1-80Vdc, Fits standard DIN rail and PCB mountable sockets, LED input status indicator, AC or DC control voltage available, cUL listed, IEC rated, CE and RoHS compliant Motor Controller Rating.
attribute :
Minimum Voltage Control (V) : 18dc
Maximum voltage regulation (V) : 32dc
Maximum load voltage (V) : 48dc
Minimum load voltage (V) : 1dc
Sensata / Crydom Solid State Relay 1a Contact
#Grup produk P111351420
Spesifikasi
| Contact Configuration | 1a(SPST) |
|---|---|
| Dimensions (mm) | 29×12.7×37.4 |
| Mounting Method | DIN Rail |
| Time (ms) | Maximum turn-off: 0.3 |
| Housing Material | PBT 30% GF, UL94 V-0 |
| Storage Temperature Range (°C) | -40 to 125 |
| Capacitance (pF) | Maximum 10 (Input/Output) |
| Input Current (mA) | Min 10.7, Max 19.7 |
| Isolation Voltage (Vrms) | (Input/Output) 2500 |
| Maximum Load Current (A) | 5 |
| Maximum Reverse Voltage (V) | 3 (DC) |
| Maximum Surge Current (A) | 60DC(10ms) |
| Maximum Turn-On Time (ms) | 0.6 |
| Minimum Load Current (A) | 0.0025dc |
| Minimum Voltage (V) | Turn on: 18DC, turn off: 2DC |
| Operating Temperature Range (°C) | -30～80 |
| Output Device | MOSFET |
| Switching Method | DC |
| Terminal Material | Copper w/Sulfamate Nickel Finish |
| Terminal Type | Through Hole |
