This Disc Micrometer has a non-rotating spindle and allows you measure a range of different
materials.
It offers you the following benefits:It features a non-rotating spindle and disc-shaped measuring surfaces.Measuring the root tangent length of spur and helical gearsMeasurable range of gear pitch: 0,5-6 moduleIt‘s suitable for measuring materials such as felt, rubber, cardboard and fabric.
Delivered: Including box, spanner, setting standard
Mitutoyo Disc Micrometer
#Grup produk P111293621
Spesifikasi
| Dimension L (mm) | 50 |
|---|---|
| Dimensions a (mm) | 12 |
| Dimensions b (mm) | 49 |
| Dimensions c (mm) | 5.5 |
| Flatness (µm) | 1 |
| Graduation (mm) | 0.01 |
| Maximum Permissible Error J MPE (µm) | ±6 |
| Measuring Face | Hardened steel, micro-lap finish |
| Measuring Spindle | ø6,35 mm, non-rotating, spindle pitch 0,5 mm |
| Mitutoyo Part Number | PDM-75B |
| Parallelism (µm) | 6 |
| Range (mm) | 50-75 |
| Scale | Thimble and sleeve satin chrome finish, ø18 mm |
| Type | Metric |
