The latest generation CRYSTA-Apex coordinate measuring machines, the new CRYSTA-Apex V Series, is packed with state of the art technology, necessary for performing very accurate measurements at high speed. All new, using Mitutoyo’s world-renowned ABS scales, the CRYSTA-Apex V series has a high resistance to environmental conditions and does not require to perform homing upon start-up. SMS capability enables status and service monitoring, ready for use in a Smart Factory environment.
A future proof investment, the CRYSTA-Apex V is capable of tackling any task you might have in the future thanks to its ability to change or add probe systems and software with ease.
Main benefits:Proven lightweight bridge-type construction with high rigidity air-bearings on every axisHigh accuracy, high speed and high accelerationTemperature sensors for compensation of machine and workpiece from 16° to 26°C and monitoring of the environmental temperature.ABS linear scales provide high environmental resistance and saves time at start-up as homing is not necessaryUC480 controller supporting Multi-sensor and SMS functionality (Smart Measuring System)
E0,mpe (µm): With SP25M: (1,7+4L/1000); With TP200: (1,9+4L/1000) ; With TP20: (2,2+4L/1000) L = measured length [mm]
Mitutoyo Coordinate Measuring Machines
#Grup produk P111293481
Sebelum PPN:
Rp819.999.900 - Rp1.399.999.900
Ketersediaan:
Periksa Metode Pembayaran dan Estimasi pengiriman
Spesifikasi
| Accuracy (µm) | E0, MPE from: (1,7+0,3L/100) |
|---|---|
| Air Supply Pressure (MPa) | 0.4 |
| Depth (mm) | 2000 |
| Digital Step (µm) | 0.1 |
| Loading Weight (kg) | 1200 |
| Maximum Drive Speed (mm/s) | 519 (3-axis) |
| Width (mm) | 1670 |
