FLUKE Networks Fi-3000 USB & Wifi Single/Mpo Probe with Tips Set
#Grup produk P111160633
Spesifikasi
| Altitude (m) | (Operating) 4000 (3200 with AC adapter); (Storage) 12000 |
|---|---|
| Battery Type | Lithium-ion; 10.8hour life |
| Camera Type | 5 Megapixel 1/4-inch CMOS sensor |
| Dimensions (inch) | 6.625x5.375x2.125 (with no dust cap or adapter tip) |
| Endface Illumination | Coaxial blue LED |
| Endtype Support | (Single Fiber and MPO) 1x8 (8 fibers), 1x12 (8, 10, or 12 fibers), 1x16 (16 fibers), 2x12 (16, 20, or 24 fibers), 2x16 (32 fibers) |
| Field of View (µm) | 610x460 |
| Frequency Ranges (GHz) | 2.4 (2412 to 2462MHz) |
| Humidity Range (RH non-condensing) | (Operating) 0% to 95% (0 to 35°C); (Storage) 0% to 95% (35 to 45°C) |
| Light Source Life (hour) | >100000 (LED) |
| Optional Automated Pass/Fail Test Time (s) | Less than 2 (per fiber) |
| Output Power (mW) | <100 |
| Power Adapter | (Input) 100 to 240 VAC ±10%, 50/60Hz; (Output) 15 VDC, 2 A maximum; Class II |
| Resolution | White LED |
| Resolution (µm) | 1 |
| Safety | IEC 61010-1: Pollution Degree 2 |
| Shock | 1 meter drop test |
| Temperature Range (°C) | (Operating) -10 to +45; (Storage) -10 to +60 |
| Test Limits | IEC 61300-3-35 ED. 2 MM; IEC 61300-3-35 ED. 2 SM APC; Document only |
| Vibration | 2g, 5 to 500Hz |
