KZE Female Thread 3-Part Ball Valve SS304
#Grup produk P111144334
Spesifikasi
| Bolt Washer Material | AISI 304 |
|---|---|
| Connection | Female Thread Connection |
| Packing Gland Material | AISI 304 |
| Screw Cap Material | AISI 316 |
| Sealing Ring Material | PTFE |
| Steam Washer Material | Poly PTFE |
| Structure | Straight Bore |
| Suitable Medium | Water, oil, air and some corrosive liquid |
| Type | Pneumatic |
| Valve Body Material | Stainless Steel 304 |
| Valve Stem Material | AISI 316 |
Pilih jenis produk yang diinginkan
| Nomor SKU | Model Number | Masa Persiapan Barang | Harga | Jumlah |
|---|---|---|---|---|
| Loading... | ||||
Apakah produk dengan spesifikasi yang Anda inginkan belum tersedia? Hubungi tim Layanan Pelanggan kami di sini
Informasi Produk
Description
Unique design and high platform structure. ISO5211 connection, easy to be installed.
Peringatan
- Foto pada halaman ini hanya sebagai referensi (ilustrasi) yang sesuai dengan fungsinya- Produk yang diterima akan sesuai dengan informasi model number/part number/size/warna/type/atribut yang tertera pada website.
Feature
- Unique design and beautiful appearance- High platform structure and ISO5200 connection, makes the installation of electric or pneumatic actuator to be more professional.
- Valve body is overlaid with reinforced bar, which can be permanently used in corrosion medium, and keep away from the cracking and failure during the installation
- Grinding process of the valve stem reduces the torque of electric or pneumatic valve during the installation.
- The valve body of carbon steel is phosphate coated, which won't be discolored and rusty. It is durable and beatiful.
- Screw type: NPT, BSPT, BSP ISO-228 Class A Thread
- Temperature range: PTFE : -20°C~180°C, TFM : -50°C~270°C, RPTFE: -35°C~210°C
- Nomial pressure: I000PSI (PN63) For 1/2 to 4inch
- Blowout proof stem
- Locking device
- Material: CF8M 9( DIN I.4408), Cf8 9DIN I .4308), WCB (DIN I.0619), (WCB, CF8, CF8M/I. Ti. Ni)
