Because it is small, lightweight, and an in-line type, it can be installed in the middle of the piping and does not take up much installation space.
A low-noise, totally enclosed, splash-proof outdoor type motor is used.
The pump can be disassembled and inspected without removing the piping.
A mechanical seal is used for the shaft seal, making maintenance easy.
Attribute :
Applications : Hot and cold water circulation; For various machine sets; General water supply
Permissible frequency fluctuation : Within -5%; Motor characteristics, temperature rise, etc. do not conform to the rated values.
Fluid handled : Liquid handled: Fresh water 0-100℃; Fresh water: Tap water, industrial water, well water with a pH of 5.8-8.6 and a chlorine ion concentration of 200mg/L or less
Dimension I (mm) : 194
Dimension J (mm) : G3/4
Dimension G (mm) : 0
Relative Humidity : 85% or less (no condensation)
Ambient temperature (℃) : 0–40
Standard allowable compression pressure (MPa [kgf/cm 2 ]) : 0.42(4.2)
Dimensions MW(mm) : 159
Dimensions PW(mm) : 264
Structure (impeller) : closed
Structure (shaft seal) : Mechanical seal
Material (casing) : FC200
Material (impeller) : SUS304
Material (main shaft) : SUS304
Structure (bearings) : Sealed ball bearings (inside electric motors)
Ebara LPD Type Line Pump
#Grup produk P111071861
Spesifikasi
| Discharge Port Diameter (mm) | 40 |
|---|---|
| Suction Port Diameter (mm) | 40 |
| Output (kW) | 1.5 |
| Voltage (V) | Three-phase 200 |
| Frequency (Hz) | 50 |
| Total Suction Head (m) | -6(20℃) |
| Connection Discharge Side | JIS10K standard type |
| Connection Suction Side | JIS10K thin type |
| Dimension A (mm) | 72 |
| Dimension B (mm) | 319 |
| Dimension E (mm) | 145 |
| Dimensions d (mm) | 155 |
| Discharge Amount (m³/minute) | 0.040/28.2 |
| Kinds | Line Pumps |
| Location | Indoor/Outdoor |
| Noise Level (dB) | 51 |
| Number of Poles | 2 |
| Part Number | 773-4573 (7734573) |
| Synchronization Speed (rpm) | 3000 |
| TRUSCO Number | 773-4573 |
| Total Head (m) | 0.250/22.6 |
| format | Fully enclosed, anti-splash type (outdoors) |
Pilih jenis produk yang diinginkan
| Nomor SKU | Model Number | Masa Persiapan Barang | Harga | Jumlah |
|---|---|---|---|---|
| Loading... | ||||
Apakah produk dengan spesifikasi yang Anda inginkan belum tersedia? Hubungi tim Layanan Pelanggan kami di sini
Informasi Produk
Description
Use
Hot and cold water circulationFor various machine sets
General water supply
