The 433-HA from Hofmann is a versatile camera system designed primarily for headlamp alignment in both left and right-hand drive vehicles, covering European and American low-beam configurations. Compatible with various wheel sizes, real-time data collection, and user-friendly software, this multifunctional tool aids collision shops in achieving precise headlight alignment, facilitating ease of use, and maintaining documentation for compliance and quality control purposes.
Additional Modules:
Rails (All rails kits include the specific wheels)
V shape light rails on floor (length 3 mt x 2 sections)
L shape high precision rails on floor (length 3 mt x 2 sections)
Heavy duty high precision rails in ground (length 3.5 mt x 2 sections)
V shape light rails on floor (extension length 0.70 mt x 2 sections)
L shape high precision rails on floor (extension length 0.75 mt x 2 sections)
Heavy duty high precision rails in ground (extension length 0.75 mt x 2 sections)
Optional:
Onboard printer; Dust cover; Electronic spirit level; LAN interface; Bluetooth module; Calibration device
HOFMANN Headlight Tester
#Grup produk P110899905
Spesifikasi
| Base | Unified foundation for wheel and rails |
|---|---|
| Base Bearing | Technopolymer |
| Battery | High-capacity lithium |
| Column Adjustable Height (mm) | 250 to 1500 |
| Column Rotation (°) | +/-5 |
| Column Wheel | Four ball bearings |
| Construction Standard | ISO 10604 |
| Counterweight System | Well-balanced |
| Laser Mechanism | Cross laser for precise alignment |
| Laser Unit Position | On top of the column |
| Lens Size (mm) | 280x200 (protected with glass) |
| Optical Chamber Body Finishing Color | Black Finish |
| Optical Chamber Body Material | Powder-Coated Steel |
| Optical Chamber Cover Color | Silver |
| Optical Chamber Cover Material | Thermoformed Plastic |
Pilih jenis produk yang diinginkan
| Nomor SKU | Model Number | Masa Persiapan Barang | Harga | Jumlah |
|---|---|---|---|---|
| Loading... | ||||
Apakah produk dengan spesifikasi yang Anda inginkan belum tersedia? Hubungi tim Layanan Pelanggan kami di sini
Informasi Produk
Description
Feature
- Optical Chamber features a robust black steel body with a sleek silver thermoformed plastic cover. It includes a 280mm x 200mm Fresnel lens protected by glass, a reverse display support, and a high-capacity lithium battery.- Base provides a unified foundation for the wheel and rails, allowing for +/-5° column rotation and smooth operation with technopolymer bearings.
- Column offers an adjustable height range from 250mm to 1500mm above the floor, a stable counterweight system, four ball-bearing wheels for easy movement, and an ergonomic driving handle.
- Laser Unit is positioned atop the column and includes a cross laser mechanism for precise alignment.
- Construction is designed for durability and precision, following ISO 10604 standards.
