KOGANEI Solenoid Valve 300 Series
#Grup produk P110729785
Spesifikasi
| Type | Standard type |
|---|---|
| Suitable fluid | Air |
| Rated Voltage (V) | DC 24 |
| Number of Positions | 2 |
| Type of Acting | Pilot Type |
| Assured Pressure Resistance (MPa) | 1.35 |
| Excitation Current (mA) | 240 (5.8W) |
| Insulation Resistance (MΩ) | More than 10 |
| LED Color | Red |
| Line Color | Red |
| Lubrication | Unnecessary |
| Maximum Operating Frequency (Hz) | 5 |
| Mounting Side | freedom |
| Number of Ports | 5 |
| Operating Pressure Range (MPa) | 0.15 to 0.9 |
| Operating Temperature Range (°C) | 5 to 50 |
| Operating Voltage Range (V) | 21.6 to 26.4 (24±10%) |
| Response Time (ms) | 20 at ON; 25 at OFF |
| Type of Switching | 4 direction single acting |
Pilih jenis produk yang diinginkan
| Nomor SKU | Model Number | Masa Persiapan Barang | Harga | Jumlah |
|---|---|---|---|---|
| Loading... | ||||
Apakah produk dengan spesifikasi yang Anda inginkan belum tersedia? Hubungi tim Layanan Pelanggan kami di sini
Informasi Produk
Description
Internal pilot type 2-position valve that promises reliable operation at low current. 2-position valves can be mixed and mounted on the 300 series manifold as they are. A shading coil system is used for the AC solenoid to eliminate solenoid burnout and hum. By installing a dedicated speed controller, it can be stopped more crisply and instantly.
