CHIYODA TSUSHO Fuji Long Mail Elbow Resin
#Grup produk P110277176
Spesifikasi
| Shape | Longmail elbow |
|---|---|
| Suitable fluid | Compressed air, vacuum |
| Dimension L (mm) | 48 |
| Dimension A (mm) | 23.5 |
| Dimension B (mm) | 54 |
| Connector Thread Type | R |
| Dimension C (mm) | phi 17 |
| Maximum Operating Pressure (MPa) | 1 |
| Operating Temperature Range (°C) | -5~60 |
| Operating Vacuum Pressure (kPa) | -100 |
| Screw Size (inch) | 1/4 |
| Suitable Tube | TE, TP, MTP (polyurethane tube), TN (nylon tube) |
| Suitable Tube Outer Diameter (Φmm) | 10 |
| Tube insertion length (mm) | 18.3 |
| Width Across Flats H (mm) | 17 |
