YUKEN E Series Flow Control and Relief Valves EFBG-06 Type
#Grup produk P110164890
Spesifikasi
| Metered Flow Adjustment Range (L/minute) | 2.5 to 250 |
|---|---|
| Flow Controls Rated Current (mA) | 750 |
| Flow Controls Coil Resistance (ohm) | 10 |
| Flow Controls Differential Pressure (MPa) | 0.7 |
| Design Number | 61 |
| Flow Controls Hysteresis | 3% or less |
| Flow Controls Repeatability | 1% or less |
| Maximum Flow Rate (L/minute) | 250 |
| Maximum Operating Pressure (MPa) | 24.5 |
| Pilot Connection | Internal Pilot |
| Pilot Flow at Normal (L/minute) | 1 |
| Pressure Control Coil Resistance (ohm) | 10 |
| Pressure Control Pressure Adjustment Rang (MPa) | 1.4 to 24.5 |
| Pressure Controls Hysteresis | 3% or less |
| Pressure Controls Rated Current (mA) | 880 |
| Pressure Controls Repeatability | 1% or less |
| Series Number | (EFB) Proportional ElectroHydraulic Flow Control and Relief Valve |
| Transition (L/minute) | 4 |
| Type of Mounting | Sub-Plate Mounting |
| Valve Size | 06 |
Pilih jenis produk yang diinginkan
| Nomor SKU | Model Number | Masa Persiapan Barang | Harga | Jumlah |
|---|---|---|---|---|
| Loading... | ||||
Apakah produk dengan spesifikasi yang Anda inginkan belum tersedia? Hubungi tim Layanan Pelanggan kami di sini
Informasi Produk
Description
This flow control and relief valve is an energy-saving valve that supplies the minimum pressure and flow necessary for actuator drive. Since this valve controls the pump pressure by following the load pressure while keeping the differential pressure minimized, it serves as a low power-consumption energy-saving, meter-in, controlled flow control valve. Further, since a temperature compensation function is incorporated, this valve provides consistent flow control without respect to the fluid temperature.
Peringatan
- Foto pada halaman ini hanya sebagai referensi (ilustrasi) yang sesuai dengan fungsinya- Produk yang diterima akan sesuai dengan informasi model number/part number/size/warna/type/atribut yang tertera pada website
