INA Deep Groove Ball Bearing 200 Series (Laher)
#Grup produk P110024608
Spesifikasi
| Basic Dynamic Load Rating, Radial (Cr) (N) | 8100 |
|---|---|
| Basic Static Load Rating, Radial (C0r) (N) | 3700 |
| Bore Diameter (D) (mm) | 15 |
| Calculation Factor (f0) | 13.1 |
| Outside Diameter D (mm) | 35 |
| Outside Diameter Seal (D1) (mm) | 28.8 |
| Rib Diameter Inner Ring (d1) (mm) | 21.5 |
| Sealing Total Width (C2) (mm) | 11 |
| Width B (mm) | 14.4 |
| Width Outer Ring C (mm) | 11 |
Pilih jenis produk yang diinginkan
| Nomor SKU | Model Number | Masa Persiapan Barang | Harga | Jumlah |
|---|---|---|---|---|
| Loading... | ||||
Apakah produk dengan spesifikasi yang Anda inginkan belum tersedia? Hubungi tim Layanan Pelanggan kami di sini
Informasi Produk
Warning
- The photo is only a reference (illustration) according to its function- Product color refers to the product name and specifications listed on the website
- Products received will be in accordance with the information listed on the website.
