Non Brand Electric Drum Pump
#Grup produk P109987392
Spesifikasi
| UNSPSC | 40151529 |
|---|---|
| Adapter Connection Type | MNPT |
| Adapter Material | Aluminium |
| Agency Compliance | FDA Compliant |
| Bung Connection Diameter (inch) | 2 |
| Compatible Chemicals | Calcium Chloride; Glycerin; Hexane; Sodium Bicarbonate (10%) |
| Cord Length (inch) | 72 |
| Diesel Exhaust Fluid Compatible | No |
| Discharge Connection Type | Hose Barb |
| Discharge Tube Outlet Inner - Outer Diameter (inch) | 1 1/4-1 1/2 |
| Duty cycle | Intermittent |
| Explosion Proof | No |
| Food Grade | Yes |
| For Container Type | Drum |
| For Media Type | Calcium Chloride; Glycerin; Hexane; Sodium Bicarbonate |
| For use with | ELEC-GLYKIT |
| Frequency (Hz) | 60 |
| Full Load Amps (A) | 5.2 |
| Height Above Container (inch) | 14 |
| Hose Cover Material | PVC |
| Hose Inside Diameter (inch) | 1 1/2 |
| Hose Length (inch) | 96 |
| Hose Outside Diameter (inch) | 1.625 |
| Hose Tube Material | PVC |
| Housing Material - Pumps | Stainless Steel |
| Includes | Barb Fitting; Intake Tube; Motor |
| Includes Bung Adapter | Yes |
| Includes Discharge Hose | Yes |
| Includes Nozzle | No |
| Includes Suction Tube | Yes |
| Manufacturer Part Number | ELEC-GLYKIT |
| Max. Head Pressure (psi) | 20 |
| Max. Oil Flow (gpm) | 9 |
| Max. Outlet Pressure (psi) | 150 |
| Max. Viscosity (CPS) | 15000 |
| Maximum Flow Rate (GPM) | 9 |
| Maximum Fluid Temperature (°F) | 250 |
| Maximum Head Pump (ft) | 75 |
| Metered | No |
| Minimum Fluid Temperature (°F) | 33 |
| Motor (HP) | 1 |
| Motor Enclosure | ODP |
| Motor Speed (rpm) | 10500 |
| Motor Type | Electric AC |
| Noise Level (dB) | 85 |
| Nominal Voltage (VAC) | 110 |
| Not Recommended Chemicals | Hydrochloric/Muriatic Acid (100%); Hydrofluoric Acid (75%); Hydrofluoric Acid 100%; Sulfuric Acid (10% - 75%); Sulfuric Acid (75% - 100%) |
| Number of Phases | 1 |
| Overall Length (inch) | 48 1/2 |
| Power Source | Electric |
| Pump Connection Type | Hose Barb |
| Pump Package Type | Basic Pump with Discharge Hose |
| Rated Voltage (V AC) | 120 |
| Runs Dry | No |
| Seal Material | PTFE |
| Self Priming | Yes |
| Suction Tube Inner Diameter (inch) | 2 |
| Suction Tube Length (inch) | 39 |
| Suction Tube Material | Stainless Steel |
| Suction Tube Outer Diameter (inch) | 1 7/8 |
| Thermal Protection | Yes |
| Variable Speed | No |
| Wetted Materials | 316 Stainless Steel; Carbon; Ceramic Oxide; PTFE |
| for Container Size (gal) | 55 |
Pilih jenis produk yang diinginkan
| Nomor SKU | Model Number | Masa Persiapan Barang | Harga | Jumlah |
|---|---|---|---|---|
| Loading... | ||||
Apakah produk dengan spesifikasi yang Anda inginkan belum tersedia? Hubungi tim Layanan Pelanggan kami di sini
Informasi Produk
Description
General purpose electric drum pumps are designed for water transfer and pumping fluids other than food, fuels, or corrosives. They're used to dispense and transfer moderate to large volumes of fluid in general manufacturing and processing applications where a specialized pump isn't needed.
Peringatan
- Foto pada halaman ini hanya sebagai referensi (ilustrasi) yang sesuai dengan fungsinya- Produk yang diterima akan sesuai dengan informasi model number/part number/size/warna/type/atribut yang tertera pada website
Feature
Battery Operated Drum Pump Hose Inside Dia 1 in Max Head Pressure 15 psi Max Oil Flow 9 gpm Max Outlet Pressure 15 psi For Use With Light Detergents Oils Rated Voltage 12V DC Pump Connection ID 1 in Suction Tube OD 1 in Hose Length 60 in Suction Tube Length 36 in Cord Length 72 in Includes Bung Adapter No Runs Dry No Thermal Protection Yes Frequency (Hz) 60 Power Source Electric Variable Speed No Includes Discharge Hose Yes Self-Priming YesUlasan Produk
