SKF Double Row Angular Contact Ball Bearing With Two-Piece Inner Ring And Relubrication Feature D Type
#Grup produk P109967343
Spesifikasi
| Bore Diameter (mm) | 150 |
|---|---|
| Outside Diameter (mm) | 225 |
| Width (mm) | 73 |
| Contact Angle (°) | 40 |
| Basic Dynamic Load Rating (kN) | 182 |
| Basic Static Load Rating (kN) | 265 |
| Arrangement of Contact Angle (double-row bearing) | Back-to-back (O) |
| Axial Internal Clearance | NSTD |
| Bearing Material | Bearing Steel |
| Cage | Machined Metal |
| Coating | Without |
| Contact Type | Normal contact (two-point contact) |
| Limiting Speed (rpm) | 2000 |
| Locating Feature, Bearing Outer Ring | None |
| Matched Arrangement | No |
| Number of Rows | 2 |
| Reference Speed (rpm) | 1700 |
| Ring Type | One-piece inner and outer rings |
| Sealing | Without |
| Universal Matching Bearing | No |
Pilih jenis produk yang diinginkan
| Nomor SKU | Model Number | Masa Persiapan Barang | Harga | Jumlah |
|---|---|---|---|---|
| Loading... | ||||
Apakah produk dengan spesifikasi yang Anda inginkan belum tersedia? Hubungi tim Layanan Pelanggan kami di sini
Informasi Produk
Description
Double row angular contact ball bearing, with two-piece inner ring and relubrication feature, correspond to a pair of single row angular contact ball bearings in a back-to-back arrangement. The two-piece inner ring enables incorporation of more balls, resulting in higher load carrying capacity. The annular lubrication groove and holes in the outer ring facilitates relubrication.
Feature
- Accommodate very high axial loads in both directions, radial loads, and tilting moments- Relubrication feature
- Suitable where a stiff bearing arrangement is required
- Require less axial space than equivalent pair of single row angular contact ball bearings
