LITTELFUSE UL Class RK1 Fuse
#Grup produk P109943468
Spesifikasi
| UNSPSC | 39121608 |
|---|---|
| AC Voltage Rating (V) | 600 |
| Amps (A) | 80 |
| Body Material | Melamine |
| Body Style | Blade |
| Class | RK1 |
| Compatible Fuse Block Series | LFR |
| DC Voltage Rating (VDC) | 300 |
| Diameter (inch) | 1 5/16 |
| Element | Dual |
| Equivalent Brand and Series | Bussmann LPS-RK; Edison LESRK; Littelfuse LLSRK; Mersen A6D-R |
| Equivalent Series | A6D-R, LESRK, LLSRK, LPS-RK |
| Fits Fuse Block Style | Rejection |
| Fuse Size L x Diameter (inch) | 7 7/8x1 5/16 |
| Interrupt Rating (kA) | 200 at 600V AC; 20 at 300V DC |
| Length (inch) | 7 7/8 |
| Series | LLSRK |
| Speed | Time Delay |
| Standards | CE; CSA Certified; QPL-W-F-1814; UL 248-12 Class RK1 |
| Visual Indication | Nonindicating |
Pilih jenis produk yang diinginkan
| Nomor SKU | Model Number | Masa Persiapan Barang | Harga | Jumlah |
|---|---|---|---|---|
| Loading... | ||||
Apakah produk dengan spesifikasi yang Anda inginkan belum tersedia? Hubungi tim Layanan Pelanggan kami di sini
Informasi Produk
Description
Time-delay, nonindicating UL Class RK1 fuses tolerate temporary inrush currents without opening, which prevents nuisance-blowing from motor and equipment startups. Also called slow-blow Class RK1 fuses, they open to disconnect an electrical circuit when exposed to sustained loads and short circuits. They have no indicator for identifying a blown fuse, so they're sometimes used with an indicating fuse block or cover.
Feature
Fuse 30 A 600V AC 300V DC Class RK1 LLSRK Series Nonindicating Time Delay Body Style Cylindrical Rejection Interrupt Rating 200kA at 600V AC 20kA at 300V DC Fuse Size 5 in L x 13/16 in dia Length 5 in Diameter 13/16 in Equivalent Brand and Series Bussmann LPS-RK Edison LESRK Littelfuse LLSRK Mersen A6D-R Equivalent Series A6D-R LESRK LLSRK LPS-RK Compatible Fuse Block Series LFR Body Material Melamine Dual ElementUlasan Produk
