LITTELFUSE UL Class & Midget Fuse Block
#Grup produk P109936264
Spesifikasi
| UNSPSC | 39121411 |
|---|---|
| Body Material | Thermoplastic |
| Connector Type | Box Lug |
| Fits Fuse Type | Industrial |
| Fuse Block Design | Open |
| Mounting Style | Bolt-Down; DIN Rail |
| Number of Poles | 3 |
| Spring Reinforced Clip | Yes |
| Standards | CSA Certified; RoHS; UL Listed |
| Wire Range (AWG) | 14 to 6 |
Pilih jenis produk yang diinginkan
| Nomor SKU | Model Number | Masa Persiapan Barang | Harga | Jumlah |
|---|---|---|---|---|
| Loading... | ||||
Apakah produk dengan spesifikasi yang Anda inginkan belum tersedia? Hubungi tim Layanan Pelanggan kami di sini
Informasi Produk
Description
These fuse blocks are compatible with UL class CC fuses rated up to 30A, 600VAC for overcurrent protection of branch circuits, control circuits, lighting, transformers, and general loads. They are rejection-style blocks that prevent midget fuses from being installed.
Feature
Fuse Block Fits Fuse Type Class CC Fuse UL Class CC 0 to 30 A Number of Poles 2 600V AC/DC For Fuse Size 1 1/2 in L x 13/32 in dia Compatible Fuse Series ATDR ATMR ATQR CCMR FNQ-R KLDR KLKR KTK-R LP-CC Series L600C Nonindicating Rejection Fuse Block Design Open Wire Range 14 to 10 AWG Mounting Style Bolt-Down Body Material Thermoplastic Connector Type Pressure Plate Height 1.25 in Width 1.53 in Length 3 in Spring Reinforced Clip NoUlasan Produk
