Nvent Erico Pipe, Rod & Wire Grounding Clamp
#Grup produk P109850195
Spesifikasi
| UNSPSC | 39121202 |
|---|---|
| For Max. Ground Conductor Wire Size (AWG) | 4 SOL |
| For Min. Ground Conductor Wire Size (AWG) | 6 SOL |
| For Rod Diameter (inch) | 5/8 |
| For use with | Galvanized Rod |
| Grounding Wire Size (AWG) | 4 to 6 SOL |
| Grounding Wires Connected To | 5/8 in Rod |
| Material | Copper |
| Number of Grounding Wires | 1 |
| Standards | cULus; RUS |
| Type - Grounding Connector | Hammer |
Pilih jenis produk yang diinginkan
| Nomor SKU | Model Number | Masa Persiapan Barang | Harga | Jumlah |
|---|---|---|---|---|
| Loading... | ||||
Apakah produk dengan spesifikasi yang Anda inginkan belum tersedia? Hubungi tim Layanan Pelanggan kami di sini
Informasi Produk
Description
These ground rod clamps permanently install with a hammer for a connection that withstands ground faults and lightning transients. Conductors are placed inside the clamp, and the clamp fits onto the top of a grounding rod. A hammer blow seals the connection.
Feature
Grounding Connector Grounding Wire Size 4 to 6 AWG SOL Material Copper Number of Wires - Grounding 1 For Maximum Ground Conductor Wire Size 4 AWG SOL For Minimum Ground Conductor Wire Size 6 AWG SOL For Use With Galvanized Rod Grounding Wires Connected To 5/8 in Rod Standards cULus RUS Type - Grounding Connector Hammer Accessory Type Ground Clamp For Rod Dia 5/8 inUlasan Produk
