POWER FIRST Insulation-Displacement Wire Connector
#Grup produk P109802851
Spesifikasi
| UNSPSC | 39121409 |
|---|---|
| Color | Brown |
| Compatible with Product Type | Insulated Stranded Copper Cable |
| Connector Type | Run Tap |
| Contact Finish | Tin |
| Contact Material | Brass |
| Fill Material | No Fill |
| Flammability Rating | V-2 |
| Insulation Material | Polypropylene |
| Max. Insulation Diameter (mm) | 0.189 |
| Max. Run Wire Size (AWG) | 10 |
| Max. Tap Wire Size (AWG) | 14 |
| Maximum Operating Temperature (°F) | 221 |
| Maximum Run Conductors | 1 |
| Maximum Tap Conductors | 1 |
| Maximum Voltage (V) | 600 |
| Min. Run Wire Size (AWG) | 12 |
| Min. Tap Wire Size (AWG) | 14 |
| Number of Ports | 1 |
| RohS Compliant | Yes |
| Run Wire Size Range (AWG) | 12 - 10 |
| Standards | UL/cUL Listed E96029 |
| Tap Wire Size Range (AWG) | 14 - 14 |
| Wire Type | Electrical |
Pilih jenis produk yang diinginkan
| Nomor SKU | Model Number | Masa Persiapan Barang | Harga | Jumlah |
|---|---|---|---|---|
| Loading... | ||||
Apakah produk dengan spesifikasi yang Anda inginkan belum tersedia? Hubungi tim Layanan Pelanggan kami di sini
Informasi Produk
Description
These insulation-displacement connectors have one port for attaching a tap wire to an existing run wire to extend the connection.
Feature
Insulation Displacement Connector Color Brown Connector Type Run Tap Insulation Material Polypropylene Maximum Insulation Diameter 0.189 mm Maximum Operating Temperature 221 Degrees F Maximum Run Conductors 1 Maximum Run Wire Insulation Diameter Not Applicable Minimum Run Wire Size 12 AWG Maximum Run Wire Size 10 AWG Maximum Tap Conductors 1 Maximum Tap Wire Insulation Diameter Not Applicable Minimum Tap Wire Size 14 AWG Maximum Tap Wire Size 14 AWG Maximum Voltage 600 VUlasan Produk
