REED INSTRUMENTS Multi-Channel Handheld Temperature Meter
#Grup produk P109671057
Spesifikasi
| UNSPSC | 41112210 |
|---|---|
| Auto Power OFF | Yes |
| Backlit | Yes |
| Battery Type | (6) AA |
| Brand | REED INSTRUMENTS |
| Data Hold | Yes |
| Data Logging | Yes |
| Data Output Type | RS-232 |
| Digit Height (mm) | 20 |
| Digital Display | 38 mm H x 53 mm W Display with 3.5-Digit Backlit LCD - 20 mm Digit Height |
| Display Height (mm) | 38 |
| Display Size HxW (mm) | 38x53 |
| Display Type | LCD |
| Display Width (mm) | 53 |
| For RTD Type | Pt 100 |
| For Thermocouple Type | Type E; Type K; Type J; Type R; Type S; Type T |
| Functions | °F/°C Switchable; 2-Channel RTD Temperature Measurement; 4-Channel Thermocouple Temperature Measurement; Data Hold; Date/Time Stamp; Low Battery Indication; Maximum and Minimum Indicators; Thermocouple Input Type |
| Graduation accuracy (mm) | ±0.4% +1 |
| Humidity Range | 10% to 85% |
| Included Probes | Mini-Type |
| Includes | Batteries |
| Includes Batteries | Yes |
| Includes NIST-Traceable Certificate | No |
| Includes Wireless Transmission | No |
| Measurement Accuracy (kPa) | ±0.4% +1.8 |
| Memory | Min/Max |
| Number of Channels | 4 |
| Number of Digits | 3.5 |
| Power Source Details | (6) AA Batteries |
| RTD Resistance (ohm) | 100 |
| RTD Temperature Range (°C) | -199.9 to 850 |
| RTD Temperature Range (°F) | -327.9 to 1,562 |
| Resolution (°C) | 0.1, 1 |
| Resolution (°F) | 0.1, 1 |
| Response Time (s) | 1 |
| Sensor Type | RTD; Thermocouple |
| Temperature Meter Type | Multichannel Thermocouple Temperature Meter with Data Output and Min/Max |
| Temperature Range (°C) | -100 to 1,700 (Thermocouple), -199.99 to 850 (RTD) |
| Temperature Range (°F) | -148 to 3,092 (Thermocouple), -327.9 to 1,562 (RTD) |
| Thermocouple Temperature Range (°C) | -100 to 1,150 (Type J); -100 to 1,300 (Type K); -100 to 400 (Type T); -100 to 900 (Type E); 0 to 1,500 (Type S); 0 to 1,700 (Type R) |
| Thermocouple Temperature Range (°F) | -148 to 1,652 (Type E); -148 to 2,102 (Type J); -148 to 2,372 (Type K); -148 to 752 (Type T); 32 to 2,732 (Type S); 32 to 3,092 (Type R) |
Pilih jenis produk yang diinginkan
| Nomor SKU | Model Number | Masa Persiapan Barang | Harga | Jumlah |
|---|---|---|---|---|
| Loading... | ||||
Apakah produk dengan spesifikasi yang Anda inginkan belum tersedia? Hubungi tim Layanan Pelanggan kami di sini
Informasi Produk
Description
These handheld temperature meters are compatible with thermocouples, thermistors, and RTDs to measure different types of samples simultaneously. They’re built with a data- logging feature that allows data to be stored, transferred, and uploaded to external sources like a PC.
Feature
Thermocouple Thermometer RTD Thermocouple Number of Channels 2 4 Includes NIST-Traceable Certificate No Accuracy +/-0.4 Percent +1.8 Degrees F/1 Degrees C -148 Degrees to 3 092 Degrees F/-100 Degrees to 1 700 Degrees C (Thermocouple) -327.9 Degrees to 1 562 Degrees F/-199.99 Degrees to 850 Degrees C (RTD) (6) AA 38 mm H x 53 mm W Display with 3.5-Digit Backlit LCD - 20 mm Digit HeightUlasan Produk
