PIC GAUGES Hydraulic Press & Cylinder Pressure Gauge
#Grup produk P109669511
Spesifikasi
| UNSPSC | 41112403 |
|---|---|
| Accuracy | ±3-2-3% |
| Accuracy Scale | Mid-Scale |
| Adjustable Pointer | No |
| Application | Hydraulics |
| Bezel Material | Stainless Steel |
| Bezel Mounting Type | Fixed |
| Blowout Safety Back | No |
| Brand | PIC GAUGES |
| Case Color | Metallic |
| Case Depth (inch) | 1.4 |
| Case Diameter (inch) | 2.8 |
| Case Material | Stainless Steel |
| Dial Color | White |
| Field Fillable | Yes |
| Freeze Resistant Movement | No |
| Gauge Case Liquid | Glycerin |
| Gauge Lens Material | Plastic |
| Gauge Wetted Parts | Copper |
| Graduations (psixbar) | 500/50 |
| Hazardous Location Rating | Not Rated |
| Hydraulic Pressure Gauge Type | Dial Pressure Gauge for Hydraulic Systems |
| IP/NEMA Rating | IP66 |
| Includes | Vent Plug |
| Includes Mounting Hardware | No |
| Includes Vent Plug | Yes |
| Lens Material | Polycarbonate |
| Liquid-Filled Case | Yes |
| Mounting Type | Stem-Mount |
| Nominal Dial Size (inch) | 2-1/2 |
| Operating Temperature Range Ambient (°F) | 30 to 160 (Glycerin Filled) |
| Panel Mountable | No |
| Pointer Color | Black |
| Pressure Gauge Type | Hydraulic Cylinder Pressure Gauge |
| Pressure Range (psi) | 0 to 3,000 |
| Pressure Range Type | Pressure |
| Primary Range (psi) | 0 to 3,000 |
| Primary Scale Minor Graduations | 50 |
| Primary Scale Numeric Increments | 500 |
| Primary Units | psi |
| Process Connection (inch) | 1/4 SAE Male |
| Process Connection Gender | Male |
| Process Connection Location | Bottom |
| Process Connection Size (inch) | 1/4 |
| Process Connection Type | SAE |
| Removable Bezel | No |
| Requires Adapter | No |
| Scale Type | Single |
| Secondary Range | bar |
| Secondary Units | bar |
| Sensor Material | Copper Alloy |
| Series | 201L |
| Socket Material | Copper Alloy |
| Standards | ASME |
| Vibration Resistance | Liquid-Filled |
| Wetted Parts Material | Copper Alloy |
Pilih jenis produk yang diinginkan
| Nomor SKU | Model Number | Masa Persiapan Barang | Harga | Jumlah |
|---|---|---|---|---|
| Loading... | ||||
Apakah produk dengan spesifikasi yang Anda inginkan belum tersedia? Hubungi tim Layanan Pelanggan kami di sini
Informasi Produk
Description
These dial load and pressure gauges use a dual-scale to measure system pressure and force. Load gauges measure external load pressure supported by jacks or cylinders, pressing parts together under predetermined loads, weighting, and testing. Pressure gauges measure input pressure into cylinders, jacks, and high-pressure systems.
Feature
Pressure Gauge 0 to 3000 psi 2 1/2 DialUlasan Produk
