CURRENT Dimmable Fluorescent Ballast
#Grup produk P109601818
Spesifikasi
| UNSPSC | 39111801 |
|---|---|
| Amps AC (A) | 2.02 |
| Ballast Bulb Type | T5 |
| Ballast Factor | 0.99 to 1.05 |
| Ballast Start Type | Programmed |
| Ballast Type | Electronic |
| Brand and Series | UltraStart(R) |
| CA Title 20 Compliant | Yes |
| Dimming | Yes |
| Dimming Method | Proprietary |
| Dimming Range (%) | 100/30 |
| Dimming Type | Step Dimming |
| Frequency (Hz) | 50 |
| Height (inch) | 1-3/16 |
| Input Power (W) | 227 |
| Input Voltage (V) | 120 to 277 AC |
| Length (inch) | 16-11/16 |
| Maximum Bulb Watts (W) | 54 |
| Minimum Starting Temperature (°F) | 0 (zero) |
| Number of Bulbs Supported | 4 |
| Operating Amps @ 120V (A) | 0.48 |
| Power Factor | Greater Than 0.99 |
| Sockets Included | No |
| Standards | Class A, Product Contributes To Reducing Energy Consumption |
| Starter Required | No |
| Thermal Protection | No |
| Total Harmonic Distortion (%) | Less Than 10 |
| Width (inch) | 1-11/16 |
| Wiring Type | Parallel |
Pilih jenis produk yang diinginkan
| Nomor SKU | Model Number | Masa Persiapan Barang | Harga | Jumlah |
|---|---|---|---|---|
| Loading... | ||||
Apakah produk dengan spesifikasi yang Anda inginkan belum tersedia? Hubungi tim Layanan Pelanggan kami di sini
Informasi Produk
Description
Two-phase step dimming ballasts are compatible with two-phase step dimming controls and are used in fluorescent lighting fixtures in classrooms, hallways, and other settings that don't require a wide range of dimming. They alter the supply voltage to dim the fixtures' light output to specific levels, for example 100% (full brightness), 50%, and 0% (off).
Peringatan
- Foto hanya sebagai referensi (ilustrasi) yang sesuai dengan fungsinya- Warna produk mengacu pada nama dan spesifikasi produk yang tertera pada website
- Produk yang diterima akan sesuai dengan informasi yang tertera pada website
Feature
UltraStart(R) Electronic Fluorescent Ballast Ballast Start Type Programmed Input Voltage 120 to 277V AC Number of Bulbs Supported 4 Max Bulb Watts 54 W Ballast Bulb Type T5 Dimming Yes Dimming Type Step Dimming Dimming Method Proprietary Dimming Range 100 Percent/30 Percent CA Title 20 Compliant Yes Min Starting Temp 0 Degrees FUlasan Produk
