TRITAN Angular Contact Ball Bearing
#Grup produk P109583053
Spesifikasi
| UNSPSC | 31171504 |
|---|---|
| ABEC Rating | 1 |
| Ball Material | Alloy Steel |
| Ball Material Grade | AISI 52100 |
| Bearing Type | Single Bearing |
| Cage Material | Polyamide |
| Load Direction | Radial; Thrust |
| Lubricant Material | Polyrex EM Grease; SRI 2 Grease |
| Matched Bearing Type | Not Matched/Single Bearing |
| Maximum Temperature (°C) | 175 |
| Minimum Temperature (°C) | -40 |
| Number of Rows | Two |
| Ring Material | Alloy Steel |
| Ring Material Grade | AISI 52100 |
| Standards | ISO Certified 9001 |
Pilih jenis produk yang diinginkan
| Nomor SKU | Model Number | Masa Persiapan Barang | Harga | Jumlah |
|---|---|---|---|---|
| Loading... | ||||
Apakah produk dengan spesifikasi yang Anda inginkan belum tersedia? Hubungi tim Layanan Pelanggan kami di sini
Informasi Produk
Description
High-clearance double-row angular contact ball bearings have more space within the bearing housing. They are useful when there is an increased press fit on the housing, elevated temperatures that may cause expansion, or a slight misalignment between the housing and the shaft. The double row of bearings allows it to act as a matching set of singular bearings arranged back-to-back, or a duplex, while saving space on the shaft.
Peringatan
- Foto pada halaman ini hanya sebagai referensi (ilustrasi) yang sesuai dengan fungsinya - Produk yang diterima akan sesuai dengan informasi model number/part number/size/warna/type/atribut yang tertera pada websiteFeature
Angular Contact Ball Bearing Ball Material Alloy Steel Bearing Industry Number 5200 Bore Diameter 10 mm Cage Material Polyamide Closure Double Shielded Contact Bearing Type Angular Contact Lubricant Material SRI 2 Grease Polyrex EM Grease Matched Bearing Type Not Matched/Single Bearing Maximum Speed 19 000 RPM Maximum Temperature 175 Degrees C Minimum Temperature -40 Degrees C Number of Rows Two Outside Diameter 30 mm Overall Width 14.3 mm Ring Material Alloy SteelUlasan Produk
