PULSAFEEDER Paddlewheel Flowmeter
#Grup produk P109574815
Sebelum PPN:
Rp6.699.900 - Rp30.999.900
Ketersediaan:
Periksa Metode Pembayaran dan Estimasi pengiriman
Spesifikasi
| Accuracy (%) | ±1.5 |
|---|---|
| Cable Length (ft) | 12 |
| Compatible Flow Material | Water |
| Connection Type | NPT |
| Display Type | Analog |
| For Pipe Size (inch) | 3/4 to 2 |
| Housing Material | Brass |
| Includes Flow Rate Adjustment Knob | No |
| Includes Pressure Gauge | No |
| Includes Totalizer | Yes |
| Max. Viscosity (SUS) | 31 |
| Maximum Media Temperature (°F) | 105 |
| Maximum Operating Pressure (psi) | 150 |
| Maximum Voltage (V) | 24 DC |
| Media Temperature Range (°F) | 35 to 105 |
| Minimum Media Temperature (°F) | 35 |
| Mounting Location | Inline |
| Mounting Orientation | Universal |
| O-Ring Materials | Natural Rubber |
| Output Type | Scaled Pulse |
| Product Type | Water Meter |
| Rotor Material | Plastic |
| Seal Material | Natural Rubber |
| Standards | AWWA C-708 |
| Unit of Measure | Gallons |
Pilih jenis produk yang diinginkan
| Nomor SKU | Model Number | Masa Persiapan Barang | Harga | Jumlah |
|---|---|---|---|---|
| Loading... | ||||
Apakah produk dengan spesifikasi yang Anda inginkan belum tersedia? Hubungi tim Layanan Pelanggan kami di sini
Informasi Produk
Description
Inline multi-jet flowmeters are used for monitoring and measuring flow rates of low-quality water at low and high flow rates for various applications, such as wastewater treatment.
Feature
Mechanical Flowmeter Product Type Water Meter Accuracy +/-1.5 Percent Connection Size 3/4 in Connection Type NPT Compatible Flow Material Water Media Temperature - Maximum 105 Degrees F Media Temperature - Minimum 35 Degrees F Viscosity - Maximum 31 SUS Voltage - Maximum 24V DC Housing Material Brass Rotor Material Plastic O-Ring Material Natural Rubber Seal Material Natural Rubber Shaft Material Tungsten Steel Wetted Material Brass Thermoplastic Standards AWWA C-708Ulasan Produk
