GEMS SENSORS Turbine Flowmeter & Totalizer
#Grup produk P109560238
Sebelum PPN:
Rp4.399.900 - Rp4.499.900
Ketersediaan:
Periksa Metode Pembayaran dan Estimasi pengiriman
Spesifikasi
| UNSPSC | 41112501 |
|---|---|
| Accuracy (%) | ±3 |
| Cable Length (ft) | 3 |
| Connection Size (inch) | 3/8 |
| Connection Type | NPT |
| Filter Rating (micron) | 50 |
| Flowmeter Type | Turbine |
| Housing Material | Nylon |
| Includes | Cable |
| Inlet/Outlet Connection (inch) | 3/8 NPT |
| Max. Viscosity (SUS) | 81 |
| Maximum Operating Pressure (psi) | 200 |
| Maximum Operating Temperature (°F) | 212 |
| Maximum Voltage (V) | 24 DC |
| Minimum Operating Temperature (°F) | -4 |
| Overall Height (inch) | 1.3 |
| Overall Length (inch) | 2.2 |
| Overall Width (inch) | 0.7 |
| Standards | CE Certified; CSAus Certified; RoHS |
| Termination (ft) | 3 Cable |
| Transistor Circuit Type | NPN |
| Voltage Range (V) | 24 DC |
| Wetted Material | Nylon; PTFE Graphite |
Pilih jenis produk yang diinginkan
| Nomor SKU | Model Number | Masa Persiapan Barang | Harga | Jumlah |
|---|---|---|---|---|
| Loading... | ||||
Apakah produk dengan spesifikasi yang Anda inginkan belum tersedia? Hubungi tim Layanan Pelanggan kami di sini
Informasi Produk
Description
Inline turbine flow sensors have an output connection to a separate monitoring system. These sensors monitor and measure the flow rate of media traveling through a system.
Peringatan
- Foto pada halaman ini hanya sebagai referensi (ilustrasi) yang sesuai dengan fungsinya - Produk yang diterima akan sesuai dengan informasi model number/part number/size/warna/type/atribut yang tertera pada websiteFeature
Flow Rate Sensor Flowmeter Type Turbine Connection Size 3/8 in Connection Type NPT Flow Rate - Maximum 1.3 gpm Flow Rate - Minimum 0.13 gpm Viscosity - Maximum 81 SUS Housing Material Nylon Filter Rating - Maximum 50 micron Operating Pressure - Maximum 200 psi Accuracy +/-3 Percent Output Frequency 575 Hz Voltage - Maximum 24V DC Pulse Rate 26 200 pulses/gal Wetted Material Nylon PTFE Graphite Standards CE Certified CSAus Certified RoHS Cable Length 3 ft Includes CableUlasan Produk
