HONEYWELL HOME Ignition Controls
#Grup produk P109423432
Sebelum PPN:
Rp7.399.900 - Rp21.999.900
Ketersediaan:
Periksa Metode Pembayaran dan Estimasi pengiriman
Spesifikasi
| Control Voltage (VAC) | 24 |
|---|---|
| Flame Sensor Current Output (uA) | 1 |
| For Fuel Type | LP; Natural Gas |
| Frequency (Hz) | 60 |
| Ignition Cycle Time (s) | 90 (Spark) |
| Lock Out Time (s) | 15 |
| Main Valve Current Output (A) | 24 |
| Maximum Operating Temperature (°F) | 165 |
| Minimum Operating Temperature (°F) | -40 |
| Number of Retries | 3 |
| Operating Temperature Range (°F) | -40 to 165 |
| Pre-Purge Time (s) | 30 |
| Replacement Type | Universal |
| Thermostat Anticipator Setting | Thermostat Anticipator |
Pilih jenis produk yang diinginkan
| Nomor SKU | Model Number | Masa Persiapan Barang | Harga | Jumlah |
|---|---|---|---|---|
| Loading... | ||||
Apakah produk dengan spesifikasi yang Anda inginkan belum tersedia? Hubungi tim Layanan Pelanggan kami di sini
Informasi Produk
Description
Intermittent pilot ignition controls use a spark and pilot light to ignite the primary burner in a combustion heater. They reduce wear and tear on electric ignitors due to their limited runtime.
Feature
Intermittent Pilot Ignitor Product Type Intermittent Pilot Ignitor Maximum Operating Temperature 165 Degrees F Minimum Operating Temperature -40 Degrees F Lock Out Time 15 sec Pre-Purge Time 30 sec Number of Retries 3 Main Valve Current Output 24 A Flame Sensor Current Output 1 uA Ignition Cycle Time 90 seconds (Spark) Automatic Reset Time 5 min Control Voltage 24V AC Thermostat Anticipator Setting Thermostat Anticipator Input Voltage 24V AC For Fuel Type LP Natural GasUlasan Produk
