BELL GOSSETT High-Efficiency Plate Heat Exchangers
#Grup produk P109420037
Sebelum PPN:
Rp10.999.900 - Rp86.999.900
Ketersediaan:
Periksa Metode Pembayaran dan Estimasi pengiriman
Spesifikasi
| UNSPSC | 40101802 |
|---|---|
| Application | Liquid and Oil Cooling; Refrigerant Evaporators and Condensers; Residential Hydronic Systems |
| Brazing Material | Copper |
| Channel Plate Material | Stainless Steel |
| Connection Material | Stainless Steel |
| Cover Plate Material | Stainless Steel |
| Fluid Compatibility | Glycol; Oil; Refrigerant; Steam; Water |
| Heat Exchanger Type | Braze Plate |
| Maximum Operating Temperature (°F) | 450 |
| Maximum Pressure Rating (psig) | 435 |
| Minimum Operating Temperature (°F) | -310 |
| Operating Temperature Range (°F) | -310 to 450 |
| Pipe Connection Gender | Male |
| Pipe Connection Type | NPT |
Pilih jenis produk yang diinginkan
| Nomor SKU | Model Number | Masa Persiapan Barang | Harga | Jumlah |
|---|---|---|---|---|
| Loading... | ||||
Apakah produk dengan spesifikasi yang Anda inginkan belum tersedia? Hubungi tim Layanan Pelanggan kami di sini
Informasi Produk
Description
Brazed plate heat exchangers use a series of plates that are welded together to create a strong, corrosion-resistant, and permanent bond. This design allows them to withstand high pressures and temperatures and provide rapid, efficient heat transfer from one fluid to the other. They are commonly used with corrosive fluids that are free of particulates or other debris that would require disassembly for maintenance.
Feature
Heat Exchanger Heat Exchanger Type Braze Plate Heat Dissipation Capacity for Water 500 000 BtuH Heat Dissipation Capacity for Oil 50 900 BtuH Total Surface Area 7.9 sq ft Overall Height 12 1/4 in Overall Width 4 3/8 in Overall Depth 3 1/4 in Maximum Pressure Rating 435 psig Maximum Operating Temperature 450 Degrees F Minimum Operating Temperature -310 Degrees F Flow Capacity 50 gpm Pipe Connection Size 1 in Channel Plate Material Stainless SteelUlasan Produk
